Home>Products>Hose Clamps>1 Hole Strap
Product name :  1 Hole Strap
Material :
 Enlarge Image                   Back
             [Next Product]→


Details:

1 Hole Strap



Products Technical Date:

1. Show:

1 Hole Strap

2. Material:

Galvaized Steel(Default), Stainless Steel(Customizable)

3. Packaging:

PE film bags coated with carton.

4. Sizes:

Part No. Matched Conduit OD(mm) Width(mm) Thickness(mm) Hole Diamter(mm)
Flex-DBKG-DN4 4 9.7 0.8 5.2
Flex-DBKG-DN6 6 9.7 0.8 5.2
Flex-DBKG-DN8 8 9.7 0.8 5.2
Flex-DBKG-DN10 10 9.7 0.8 5.2
Flex-DBKG-DN12 12 9.7 0.8 5.2
Flex-DBKG-DN14 14 9.7 0.8 5.2
Flex-DBKG-DN16 16 15 1.0 6.4
Flex-DBKG-DN18 18 15 1.0 6.4
Flex-DBKG-DN20 20 15 1.2 6.4
Flex-DBKG-DN25 25 20 1.2 8.4
Flex-DBKG-DN32 32 20 1.2 8.4
Flex-DBKG-DN40 40 20 1.5 8.4
Flex-DBKG-DN50 50 20 1.5 8.4



Shpping & Payment:

MOQ: 100pcs.

Payments: T/T, Western Union, Paypal are available. Others are negotiated.

Customizable Service: 1 hole strap customizable is workable for us. Such as sizes, logo, packing quantity, packages etc.
